High-performance/high-quality fluorescence filter cubes for research that demands precise signal detection.

Nikon offers a wide range of fluorescence filter cubes with high fluorescence acquisition efficiency to support imaging of a large variety of fluorophores and fluorescent proteins. The large product range includes longpass filter cubes for observation of single-stained samples and bandpass filter cubes suitable for detecting specific wavelengths from multiple-stained samples and un-mixing. All fluorescence filters are manufactured utilizing the most advanced hard-coat sputtering techniques available for precision and durability.

›Wavelengths with an extremely sharp rising edge characteristic.
›High transmittance from 93% to 97% (both excitation and barrier filters).
›High fluorescence acquisition efficiency, enabling reduced excitation intensity and sample fading.
›All series filters are made of glass with high dimensional accuracy which eliminates the possibility of image shifts when superimposing multi-color images and ensure accurate imaging even in the case of fluorophores with small Stokes shifts.
